200gsm Non-Woven Geotextile Membrane – Landscaping & Drainage Fabric
200gsm Non-Woven Geotextile Membrane – White
This 200gsm white non-woven geotextile membrane is a heavier duty version of our standard landscaping fabric, offering excellent drainage, filtration, and separation properties with increased durability for projects that require a stronger material.
With a higher tensile strength and excellent water permeability, this membrane is ideal for both domestic and commercial landscaping and construction projects. The heavier weight fabric provides reliable ground separation while still allowing water to pass through efficiently.
Manufactured using thermally bonded fibres, this commercial grade membrane is tough, versatile, and designed to withstand higher loading conditions compared with lighter weight fabrics. A UV inhibitor is also added to improve durability during installation and outdoor use.
Key Features
• Heavy duty 200gsm non-woven geotextile membrane
• Excellent drainage and filtration performance
• Higher tensile strength for increased durability
• Ideal for separation and ground stabilisation
• Thermally bonded fibres for improved strength
• UV inhibitor added for enhanced outdoor performance
• Suitable for domestic and commercial projects
Membrane Size Options
This membrane is supplied as a 2.25m wide roll with a range of cut lengths available.
Available sizes:
• 2.25m x 5m – 11.25m²
• 2.25m x 10m – 22.5m²
• 2.25m x 20m – 45m²
• 2.25m x 100m – 225m²
The combination of strength, permeability, and durability makes this 200gsm non-woven membrane one of the most versatile general purpose geotextile fabrics available for landscaping and construction projects.
|
Test |
Standard |
200GSM Fabric Score |
|
Tensile Strength (kN/m) |
EN 10319 |
18 |
|
Elongation at maz load (%) |
EN10319 |
50 |
|
CBR Puncture resistance (N) |
EN ISO 12236 |
2900 |
|
Cone Drop Penetration (mm) |
EN 918 |
18 |
|
Pore size 90% finer than (microns) |
EN ISO 12956 |
70 |
|
Water permeability (x 10-3) (m/sec) 11058 |
EN ISO |
80 |
|
Effect of UV light |
- |
Contains Inhibitor |
CE marked and manufactured under BS EN ISO 9001
PLEASE NOTE: This item will be sent folded; the membrane is cut from a much larger roll. Larger pieces 45m2 and 225m2 will be on a roll and multiple pieces supplied will be cut as one piece for easy transportation.
Check out our handy blog section for tips and tricks to lay you membranes successfully.
